E70RH-I-MW600-CB

NPI
RND
NRND
EOL
Product Lifecycle Status: Recommended for New Designs

$110.34

5 in stock

Get Quote
SKU: E70RH-I-MW600-CB
Attribute Value
Diagonal Size 7 Inches
Module Size 50.20 x 193.47mm
Viewing Area 33.60 x 170.88mm
Resolution 280 x 1424
Interface 4-Lane MIPI DSI
Brightness 600 Nits
Touch Panel Type Capacitive
TFT Controller OTA7290N
CTP Controller GT9271
Display Type IPS
Polarizer Transmissive
Operating Temperature -20C to 70C

Documentation

7.0-inch TFT Display

Description

High Brightness: Our High Brightness TFT LCDs, with brightness levels between 500 and 700 nits, ensure a luminous and vivid display even in bright indoor conditions. These high-brightness screens provide excellent visibility and color fidelity, making them an excellent choice for indoor applications that experience bright lighting, such as retail displays, commercial signage, and industrial control systems.

RoHS Compliant: All of our products are RoHS Compliant, adhering to the stringent guidelines set by the European Union's Restriction of Hazardous Substances directive. This ensures that our products are manufactured without the use of harmful materials, prioritizing the safety of our customers and the environment.

Design Resources
