3.5-inch TFT Display
Specification Sheets | Schematics | Code | Quality Documentation |
---|---|---|---|
E35RC-B-MW420-N Specification Sheet | 2 Lane MIPI Schematic | 2 Lane MIPI Code | RoHS |
E35RC-B-MW420-N DWG | REACH | ||
ILI9806E Specification Sheet | CMRT |
$75.96
11 in stock
3.5-inch TFT Display
Specification Sheets | Schematics | Code | Quality Documentation |
---|---|---|---|
E35RC-B-MW420-N Specification Sheet | 2 Lane MIPI Schematic | 2 Lane MIPI Code | RoHS |
E35RC-B-MW420-N DWG | REACH | ||
ILI9806E Specification Sheet | CMRT |
Blanview: Our Blanview TFT LCDs utilize innovative technology to achieve superior sunlight readability while maintaining low power consumption. Ideal for outdoor and mobile applications, these displays provide the perfect balance between performance, readability, and energy efficiency.
MIPI-DSI Interface: Our MIPI-DSI Interface TFT LCDs deliver high-resolution visuals and rapid data transfer for a superior display experience. These advanced displays are perfect for cutting-edge applications such as smartphones, tablets, and other high-performance devices, where stunning graphics and ultra-fast refresh rates are essential.
VGA Resolution: Our VGA (Video Graphics Array) TFT LCDs boast a resolution of 640x480 pixels, offering superior image quality and enhanced clarity for more demanding applications. These displays are perfect for use in high-resolution devices like industrial monitors, professional camera systems, and advanced gaming consoles where sharp visuals and accurate color reproduction are essential.
Transmissive Polarizer: Our Transmissive Polarizer TFT LCDs offer exceptional color reproduction and high-contrast ratios for crisp, clear visuals. These displays are ideal for indoor applications, such as multimedia systems and gaming devices, where bright and vibrant images make all the difference.
Wide Operating Temperature Range: Our Wide Operating Temperature Range LCDs are designed to perform consistently and reliably in extreme temperature conditions, making them suitable for use in harsh environments, such as industrial control systems, automotive applications, and outdoor equipment.
RoHS Compliant: All of our products are RoHS Compliant, adhering to the stringent guidelines set by the European Union's Restriction of Hazardous Substances directive. This ensures that our products are manufactured without the use of harmful materials, prioritizing the safety of our customers and the environment.
