4.3-inch TFT Display
Specification Sheets | Schematics | Quality Documentation |
---|---|---|
E43RG63248LW2M220-N Specification Sheet | 24-Bit RGB Schematic | RoHS |
E43RG63248LW2M220-N DWG | REACH | |
OTA5180A Specification Sheet | CMRT |
$39.34
3 in stock
4.3-inch TFT Display
Specification Sheets | Schematics | Quality Documentation |
---|---|---|
E43RG63248LW2M220-N Specification Sheet | 24-Bit RGB Schematic | RoHS |
E43RG63248LW2M220-N DWG | REACH | |
OTA5180A Specification Sheet | CMRT |
TN TFT: Our TN types of TFTs offer rapid response times making them ideal for fast-paced applications. With a cost-effective production process, the TN type of display is suitable for any application requiring a dynamic and responsive color display.
RGB Interface: Our TFT LCDs with RGB Interface ensure seamless connectivity and high-speed data transfer for vivid, true-to-life colors and exceptional image quality. These displays are perfect for multimedia systems, gaming consoles, and other applications where color depth and fidelity are of utmost importance.
WQVGA Resolution: Our WQVGA (Wide Quarter Video Graphics Array) TFT LCDs feature a resolution of 480x272 pixels, bringing enhanced widescreen viewing capabilities to your devices. These displays offer an excellent balance between visual quality and resource efficiency, making them perfect for applications such as automotive infotainment systems, GPS devices, and portable media players where a wider aspect ratio is desired.
Transmissive Polarizer: Our Transmissive Polarizer TFT LCDs offer exceptional color reproduction and high-contrast ratios for crisp, clear visuals. These displays are ideal for indoor applications, such as multimedia systems and gaming devices, where bright and vibrant images make all the difference.
Wide Operating Temperature Range: Our Wide Operating Temperature Range LCDs are designed to perform consistently and reliably in extreme temperature conditions, making them suitable for use in harsh environments, such as industrial control systems, automotive applications, and outdoor equipment.
RoHS Compliant: All of our products are RoHS Compliant, adhering to the stringent guidelines set by the European Union's Restriction of Hazardous Substances directive. This ensures that our products are manufactured without the use of harmful materials, prioritizing the safety of our customers and the environment.
