E24RB-FW360-N

$27.30

8 in stock

SKU: E24RB-FW360-N
Attribute Value
Diagonal Size 2.4 Inches
Module Size 42.92 x 60.26mm
Viewing Area 36.72 X 48.96mm
Resolution 240 x 320
Interface 8/9/16/18-Bit MCU, 16/18-Bit RGB, 3/4-wire Serial, 3/4-SPI
Brightness 360 Nits
Touch Panel Type No Touch Panel
TFT Controller ST7789V
CTP Controller None
Display Type VA
Polarizer Transflective
Operating Temperature -20C to 70C

Documentation

2.4-inch TFT Display

Specification SheetsSchematicsCodeQuality Documentation
E24RB-FW360-N Specification Sheet8-Bit MCU Schematic8-Bit MCU CodeRoHS
E24RB-FW360-N DWG16-Bit MCU Schematic16-Bit MCU CodeREACH
ST7789V Specification Sheet18-Bit MCU Schematic18-Bit MCU CodeCMRT
 3SPI Schematic3SPI Code
 3SPI + 16-Bit RGB Schematic3SPI + 16-Bit RGB Code
 3SPI + 18-Bit RGB Schematic3SPI + 18-Bit RGB Code
 4SPI Schematic4SPI Code
 4SPI + 16-Bit RGB Schematic4SPI + 16-Bit RGB Code
 4SPI + 18-Bit RGB Schematic4SPI + 18-Bit RGB Code

Description

Selectable RGB, MCU, or SPI Interface: Our versatile TFT LCDs with selectable RGB, MCU, or SPI interfaces offer unparalleled flexibility for integration with various systems and devices. These adaptable displays cater to a wide range of applications, from multimedia systems to embedded solutions, ensuring optimal compatibility and performance regardless of your project requirements.

QVGA Resolution: Our QVGA (Quarter Video Graphics Array) TFT LCDs have a resolution of 320x240 pixels which provides a compact display solution for a wide range of applications. This resolution creates sharp visuals and delivers reliable performance, making them ideal for use in handheld devices, industrial control systems and other applications where space is limited, and efficiency is crucial.

Transflective Polarizer: Our Transflective Polarizer TFT LCDs provide a perfect balance between transmissive and reflective properties, ensuring optimum visibility in various lighting conditions. These versatile displays work well in both indoor and outdoor environments, such as retail signage and mobile devices, where adaptability to lighting is crucial.

Wide Operating Temperature Range: Our Wide Operating Temperature Range LCDs are designed to perform consistently and reliably in extreme temperature conditions, making them suitable for use in harsh environments, such as industrial control systems, automotive applications, and outdoor equipment.

RoHS Compliant: All of our products are RoHS Compliant, adhering to the stringent guidelines set by the European Union's Restriction of Hazardous Substances directive. This ensures that our products are manufactured without the use of harmful materials, prioritizing the safety of our customers and the environment.
